     Tilo Dedinski Vorderladerwaffenbau - Germany

underhammer rifle "Billinghurst"

Underhammer rifle Whitworth 100 meter
Lupe To enlarge the picture of the rifle, please click on it.
The picture at the top has a fore-end and false muzzle.


Erfolge meiner Kunden

more successes
Informations about William Billinghurst
The price-list and other documents can be downloaded here.
Notes on how to order.

Each weapon is made by hand according to your wishes. Technical information and possibilities for the specifications can be found listed in the following.

All the lock parts are made using high-quality materials from the full piece. No molded parts are used! In this way, each weapon becomes a unique single piece. The barrel can be dismantled by using a herdened conical pin. The trigger pull weight of the fine trigger will be adjusted according to your wishes. The rifle has an excellent balance. The tang sight is adjustable for windage and elevation. The stock is from walnut wood (heartwood), better walnut wood qualities possible.

Standard configuration 100 meters / Whitworth:
p .38 caliber barrel, length of twist 600mm, 6 groves, Suhl-production Krupp steel, cold swaged)

p .42 caliber barrel, length of twist 500mm, 8 groves, Suhl-production, Krupp steel cold swaged with false muzzle or false muzzle for crosspatch
p Eichelberger-barrel with false muzzle or false muzzle for cross patches.
  false muzzle for cross patchLupe

walnut stock with cheek piece without checkering (the stock length is made to fit the shooter, left-handed stock possible)
The butt plate is made of steel and has checkering.
butt plate with checkeringLupe

Optional with fore-end

p barrel and hammer blued
p case hardened (rust-proof "stainless steel finish")
p globe front sight with interchangeable sight insert (standard Model No. 1 Korneinsatz No. 1 in Ø 3,0mm or your wishes, other versions possible)
p tang sight adjustable for windage and elevation with peep sight insert, up to 300m shooting distance. Peep sight insert in the peep sight can be changed. The standard hole size is 0.9 mm, can also be delivered in other diameters.
p nipple with tungsten carbide insert M6x1
p trigger pull weight adjusted according to customer's requirements

Technical data:
p length of barrel 800mm
p length of twist and grooves:
Standard caliber: cal. .38 / 600mm 6 grooves Suhl-production (cold swage-made and vacuum tension-free annealed).
optional: cal. .41 / 500mm 8 grooves Suhl-production (cold swage-made and vacuum tension-free annealed).
p The barrel can be easily separated from the system by removing the hardened conical pin.
p sight radius approx. 890mm
p weight round system: approx. 5,3kg
weight oval system: approx. 4,9kg

Included accessories:
p nipple key nipple key
p punch to remove the conical pin punch to remove the conical pin
p key for tang sight key for tang sight
p manual with loading data


Optional accessories:
p rifle sling rifle sling rifle slingLupe To enlarge the picture of the sling, please click on it.
p bullet mold with handles bullet mold
p sizing die
p front sight insert  globe front sight No. 1 globe front sight No. 2 globe front sight No. 3globe front sight No. 4globe front sight No. 4
p peep sight insert peep sight insert
p nipple with tungsten carbide or with platinum insert (M6x1) nipple with tungsten carbid nipple with platinum insert
p punch for cross patches punch for cross patches cross patch
p cleaning rod and loading rod with roller ball bearings cleaning rod and loading rod with roller ball bearings
p arms case with matching foam rubber inlay arms case with matching foam rubber inlay

muzzleloader engravings   Engravings and gold-inlays are available in different variations.

Examples can be found at Engravings

Your individual wishes are most welcome!

Underhammer rifle walnut luxus   Zur Auswahl stehen verschiedene Nußhölzer, die auf Wunsch auch mit Fischhaut versehen werden können.
24ct- gold monogram     24ct- gold monogram monogram engraved     monogram engraved monogram engraved in crest
24ct- gold monogram monogram engraved monogram engraved
in crest

The weapon is proof-fired in the proofhouse Suhl and shows the stamp woth sole and pick.
Suhl is the oldest proofhouse in Germany, it was founded in 1893 as the Royal Prussian Proofhouse zu Suhl.

Here you can find notes on how to order and information on cleaning and maintenance.


Test report muzzleloader Underhammer rifle Billinghurst in the magazine "Visier 5/2002"Test report Underhammer rifle in the magazine "Visier 5/2002" pdf file size 1,16 MB

Order form muzzleloader Underhammer rifle Billinghurst Whitworth Order form Underhammer rifle pdf file size 50 KB

Flyer muzzleloader underhammer rifles Billinghurst Vetterli and WhitworthFlyer Underhammer rifle pdf file size approx. 3 MB

Price-list muzzleloader Underhammer rifle 100 meters Price-list Underhammer rifle 100 meters pdf file size 50 KB

If you cannot read these documents pdf, please click on the logo: Adobe Reader and install the Adobe Reader available free-of-charge.

Please note that all descriptions, measurements and weights on these pages may vary slightly due to individual manufacturing.
